BD48100R05 U rack mounted energy storage battery adopts long-life and environment-friendly Lithium iron phosphate battery, and is equipped with high-performance BMS to effectively manage the battery cells. Compared with traditional batteries, it has more extensive performance and application advantages.
The battery used in this product is LFP 3.2V 102Ah, with a total of 16 cells used in series and parallel. The available capacity is 5.1KWh, the rated voltage is 51.2v, the Standard charge and discharge current is 50A, and the Max charge and discharge current is 100A. BMS protection has the following protection functions: Overall voltage protection, cell voltage protection, charge overcurrent protection, discharge overcurrent protection, short circuit protection, cell temperature protection, ambient temperature protection, MOS high performance protection, cell voltage difference protection, balanced function.
Rack mounted products are compatible with 90% of inverters on the market, such as Victron/SMA/GROWATT/GOODWE/
SOLIS/PLONTECH/DEYE/SODAR/SRNE/Voltronicpower/Luxpowertek/SORUIDE/Megarevo, ect. Supports off grid and grid connection. Easy to install, meeting the needs of the entire household’s energy storage system.
Sketch
- Battery Capacity: 5Kwh
- Life Cycles≥4000cls
- Working voltage range: 42 V~58.4V
- Standard charge and discharge current: 100A
Basic Parameters
- Name: BD048100R05
- Rated voltage:51.2V
- Standard Capacity: Lithium iron phosphate (LFP)
- Output Waveform:Pure Sine Wave
